      • High Speed and Efficiency

        • Rapid traverse speed up to 60m/min on all axes for exceptional productivity.
        • Complete 5-sided machining in a single setup: milling, boring, turning, drilling, reaming, tapping, and more.
        • Flexible manufacturing with optional multi-pallet system for uninterrupted production.
        • Powered by Siemens SINUMERIK ONE control system for precision and advanced automation.
        • Direct-gripper servo-driven tool changer achieves a 1.5-second tool-to-tool time.
        • Compact footprint saves valuable floor space without compromising performance.

        High Precision

        • Comprehensive cooling system ensures optimal thermal stability for prolonged machining accuracy.
        • HEIDENHAIN closed-loop grating scale system guarantees consistent precision during continuous operation.
        • High-performance German INA/SCHNEEBERGER linear guides deliver long-term durability and unwavering accuracy.
        • Non-contact laser tool measurement enables fast and precise tool setup for efficient machining.
        • Exceptional axis precision:
          • Positioning accuracy (VDI 3441): 0.006mm
          • Repeat positioning accuracy: 0.003mm

        High Stability

        • Mineral composite bed delivers exceptional thermal stability with:
          • Reduced heat distortion
          • Superior vibration damping
          • Enhanced noise reduction
        • Room-temperature curing manufacturing minimizes residual stresses for improved part accuracy.
        • Engineered reliability through:
          • Optimized structural design
          • Mature control algorithms
          • Industry-leading low failure rates
      • TECHNICAL PARAMETER

        Traverse X/Y/Z(mm)

        800/800/550

        Rapaid Traverse X/Y/Z(m/min)

        60/60/60

        Max. Vertical Height(mm)

        700

        Max. Workpiece Diameter*Height (mm)

        ⌀800*560

        Spindle

        HSK-A63

        Speed(rpm/min)

        15000/ 18000

        Measuring System

        HEIDENHAIN Linear Encoders

        Control System

        SIEMENS SINUMERIK ONE

        A-axis Swivel Range(°)

        ± 130°

        C-axis Travel(°)

        360°

        Footprint(m*m)

        • 4m*3.38m

        Weight(T)

        • 13T
      • Main Industry

        We provide comprehensive project services that from project consulting and solution implementation to cater to the diverse requirements of various industries.

        Aerospace

        Utilized in manufacturing essential components like aero-engine parts, aircraft structural parts, and aircraft landing gear.

        Energy & Power

        Manufacturing of automotive components such as bogies, front and rear axles, chassis, engine cylinder heads and blocks, gearbox housings, and motor housings.

        Medical Sectors

        Curved surfaces and small parts, etc.

        Semiconductor

        Semiconductor equipment core components such as various types of vacuum chamber.
